Intel Xeon E5-1620 v3

Server CPUIntel

Also called intel xeon e5-1620 v3, xeon e5-1620 v3, e5-1620v3, xeon-e5-1620-v3

IntelServer CPUHaswell

Intel Xeon E5-1620 v3 is a Intel processor with 4 CPU cores and 8 threads.

What you need to know

Intel Xeon E5-1620 v3 is a Intel processor with 4 CPU cores and 8 threads.

These are recorded reference specifications, not a tested performance or operating-system compatibility verdict. Confirm the exact model, variant, and platform against manufacturer documentation before changing hardware.

Specifications

Figures below follow the Feex Hardware Database record for this SKU. Fields without a recorded value are omitted.

Processor

Intel Xeon E5-1620 v3 specifications: Processor
Manufacturer Intel
Family Xeon E5
Architecture Haswell
Generation Intel Xeon Processor E5 v3 Family
Manufacturing process 22 nm
Segment Server

Cores and threads

Intel Xeon E5-1620 v3 specifications: Cores and threads
CPU cores 4
Threads 8

Clock speeds

Intel Xeon E5-1620 v3 specifications: Clock speeds
Base frequency 3.5 GHz
Maximum turbo frequency 3.6 GHz

Cache

Intel Xeon E5-1620 v3 specifications: Cache
L3 cache 10 MB

Memory

Intel Xeon E5-1620 v3 specifications: Memory
Supported types DDR4
Maximum memory 768 GB
Memory channels 4

Package and power

Intel Xeon E5-1620 v3 specifications: Package and power
Socket FCLGA2011
Processor base power 140 W
PCIe Revision 3.0, 40 lanes

Market

Intel Xeon E5-1620 v3 launched July 1, 2014 at USD 294 (suggested price at launch).

Intel Xeon E5-1620 v3 specifications: Market
Launch date July 1, 2014
Launch MSRP USD 294 (suggested price at launch)
Model E5-1620V3

Features

Intel Xeon E5-1620 v3 records 2 instruction sets on this sheet.

Intel Xeon E5-1620 v3 specifications: Features
Instruction sets
Security
Virtualization

Compatibility

Compatibility
Socket FCLGA2011
Board A shared socket is not automatic compatibility. Check the motherboard CPU list and BIOS revision.
Memory DDR4, up to 768 GB

A shared socket is not automatic compatibility. Boards often need a BIOS update before a newer chip in the same socket will post.

Cooler clearance, VRM quality, and power limits matter as much as the socket name.

Read the memory list on the board. The CPU can list more standards than one motherboard will accept.

A CPU without integrated graphics does not always require a discrete graphics card. Some server motherboards provide a separate management graphics controller. Check the motherboard and CPU documentation.

Manufacturer-checked specifications

Intel Xeon E5-1620 v3

These fields were checked against Intel's model-specific reference on 2026-10-29. Power ratings are manufacturer-defined metrics, not measured system consumption. Other imported fields have not all been independently reverified.

Intel Xeon E5-1620 v3
Code name Haswell
Manufacturer segment Server
CPU cores 4
Threads 8
Maximum turbo frequency 3.6 GHz
Base frequency 3.5 GHz
L3 cache 10 MB
Processor base power 140 W
Manufacturer launch date Q3'14
Maximum memory 768 GB
Memory channels 4
Socket or package FCLGA2011

Sources and verification

Source provenance: this sheet was imported from the Feex Hardware Database. Importing a record does not independently verify its specifications. The references below are the sources recorded for this entry.

Performance, current support, and compatibility have not been independently established by this reference. Missing specifications remain unknown.
